| Efficiency |
typ. 93 % (120 V AC) |
| typ. 94.6 % (230 V AC) |
| Nominal output voltage |
24 V DC |
| Setting range of the output voltage (USet) |
24 V DC ... 28 V DC (> 24 V DC, constant capacity restricted) |
| Nominal output current (IN) |
20 A |
| Short-circuit-proof |
yes |
| No-load proof |
yes |
| Derating |
55 °C ... 70 °C |
| Crest factor |
typ. 1.667 (120 V AC) |
| typ. 1.75 (230 V AC) |
| Output power (PN) |
480 W |
| Connection in parallel |
yes, for redundancy |
| Connection in series |
yes, for increased output voltage |
| Feedback voltage resistance |
≤ 35 V DC |
| Protection against overvoltage at the output (OVP) |
≤ 35 V DC |
| Residual ripple |
typ. 70 mVPP (with nominal values) |
| Control deviation |
< 1 % (change in load, static 10 % ... 90 %) |
| < 3 % (change in load, dynamic 10 % ... 90 %) |
| < 0.1 % (change in input voltage ±10 %) |
| Rise time |
< 1 s (UOut = 10 % ... 90 %) |
| Minimum no-load power dissipation |
< 2.9 W (120 V AC) |
| Maximum no-load power dissipation |
< 3 W (230 V AC) |
| Minimum nominal load power dissipation |
< 37 W (120 V AC) |
| Power loss nominal load max. |
< 28 W (230 V AC) |
| Signal relay 13/14 |
| Connection level |
3.x |
| Connection labeling |
3.1 (13), 3.2 (14) |
| Switch contact (floating) |
OptoMOS |
| Switching voltage |
max. 30 V AC/DC |
| max. 60 V DC |
| Current carrying capacity |
max. 50 mA |
| State condition |
UOUT > 0,9 x UN (Contact closed) |
| UOUT < 0,9 x UN (Contact open) |
