| Efficiency |
> 94 % (120 V AC) |
| > 95.5 % (230 V AC) |
| Nominal output voltage |
48 V DC |
| Setting range of the output voltage (USet) |
48 V DC ... 56 V DC (> 48 V DC, constant capacity restricted) |
| Nominal output current (IN) |
2.5 A (120 W) |
| 2 A (96 W) |
| Short-circuit-proof |
yes |
| No-load proof |
yes |
| Derating |
> 50 °C ... 70 °C (2 % / K) |
| Crest factor |
typ. 1,64 (120 V AC) |
| typ. 1.69 (230 V AC) |
| Output power (PN) |
120 W |
| 96 W |
| Connection in parallel |
yes, for increasing power and redundancy with diode |
| Connection in series |
yes, for increased output voltage |
| Feedback voltage resistance |
≤ 60 V DC |
| Protection against overvoltage at the output (OVP) |
< 60 V DC |
| Residual ripple |
typ. 100 mVPP |
| Control deviation |
< 0.5 % (Static load change 10 % ... 90 %) |
| < 3 % (Dynamic load change 10 % ... 90 %, (10 Hz)) |
| < 0.1 % (change in input voltage ±10 %) |
| Rise time |
typ. 100 ms (UOut = 10 % ... 90 %) |
| Minimum no-load power dissipation |
< 0.21 W (120 V AC) |
| Maximum no-load power dissipation |
< 0.21 W (230 V AC) |
| Minimum nominal load power dissipation |
< 7.7 W (120 V AC) |
| Power loss nominal load max. |
< 5.7 W (230 V AC) |
